The EKWHCTRL0 continuous modulation circuit board enables remote thermostat connectivity, providing full control of the fan coil system via the wall-mounted remote control. A single remote control can manage up to 30 fan coils simultaneously in broadcast mode, ensuring unified operation. Compatible with all fan coil versions, the board features a green LED to indicate operational status and detect anomalies. Key operational parameters, including the set point and room temperature, are transmitted from the remote control to all connected units. The system also includes a 10 kΩ water temperature probe within the device battery, regulating the minimum heating level (30°C) and maximum cooling level (20°C). For detailed usage instructions, refer to the control's user guide.
For use with Daikin Altherma Air Source Heat Pumps.
For use with EKWHCTRL1 remote controller
Compatible with all fan coil versions
Indicates operational status and detects problems with green LED
box is a bit squashed
